PVC Pipe Die Head

Periplast designs and fabricates tooling for PVC pipe manufacturing in several sizes and versions including spider or spiral mandrel distributors and straight-through or cross-head flow configurations.



PVC monolayer pipes in O.D. range from 25 to 1000mm



Multilayer pipes with 2 layers in O.D. up to 75 mm

Main Features

Spider type. Made of high-quality tool steel.



Chromium-plated.



Assembly trolley from Ø110mm.Spider type. Made of high-quality tool steel.

Models

Model
Capacity[mm]
Output [kg/h]
Qty.
Total Power
PVC25
12-25
50
3
1kW
PVC50
20-50
100
3
1,6kW
PVC63
20-63
120
3
2,5kW
PVC75
25-75
150
3
3,7kW
PVC90
25-90
180
3
8kW
PVC110
63-110
200
6
10kW
PVC125
63-125
200
4
10,5kW
PVC140
63-140
300
6
13kW
PVC160
75-160
400
4
12kW
PVC200
90-200
450
4
22,2kW
PVC250
90-250
-
7
-
PVC315
90-315
500
7
35kW
PVC400
110-400
700
8
65kW
PVC500
110-500
800
9
80kW
PVC630
400-630
1000
13
110kW
PVC800
500-800
1400
13
245kW
PVC1000
450-1000
1500
13
260kW
2PVC75
25-75
-
4
3,3kW
