Turbo Mixer

All internal surfaces in contact with the products are made of 316 L stainless steel with a polished inner surface. The container cover is also made of 316L stainless steel, internally polished, can be opened vertically with a lifting system by a pneumatic cylinder, has Silicone rubber seals, and a safety limit switch to stop the motor when opening.



In the cover, we can also find the inspection window, the respirator connection with the filtering sleeve, and the connection for the product inlet.
Two stainless steel probes insulated from the container with Teflon coatings and positioned laterally allow the temperature to be displayed in real-time on the control panel.
In addition to steel, the mixing tool has a Tungsten Carbide coating on the parts subject to the most friction, and all of them have a precise dynamic balance.



Extraction nut to quickly remove the tool with a special key supplied with the machine.
Single-speed A.C. driven by frequency converter.
Grease lubricated Viton sealing rings, resistant to dust and heat. Bearings with self-aligned rollers and periodically lubricated.
The mixer’s base frame is composed of welded steel offering all the stability required.
This mixer has excellent efficiency, so it allows excellent production rates and high-quality standards.

Main Features

Recipient made of 316L stainless steel



Real-time temperature control



Single speed control motor



Tungsten-coated mixing tool



Viton sealing rings

(Português)

Modelos

v
Model
Volume (l)
Power (kW)
H100/C300
100 / 300
22 / 5.5
H160/C350
160 / 350
30 / 7.5
H200/C800
200 / 800
45 / 11
H250/C1000
250 / 1000
55 / 15
H400/C1400
400 / 1400
75 / 22
H500/C1600
500 / 1600
110 / 22
H600/C1800
600 / 1800
132 / 22
H800/C2500
800 / 2500
160 / 30
H900/C3000
900 / 3000
160 / 37
H1000/C3000
1000 / 3000
200 / 37
H1200/C3500
1200 / 3500
250 / 45
H1500/C4250
1500 / 4250
315 / 55
