Plain Feed Extruder

Description
Plasticizing unit designed for the production sensitive materials, such as PE or PP, at high rates: plain feeding section and high output screw design. Nitrated screw and barrel. Degassing on 33D models. Temperature control by heating bands and/or fans/water/tempering oil. Insulated barrel for high efficiency control of temperature.

Main motor AC type and Heavy – duty gearbox with thrust bearing or high efficiency solutions in several stages of efficiency/solution and price.

Extruder controller includes: main motor control, heating/cooling of barrel (several types of) possibility of control of extra drives, feeders, etc.

Specs

Other L/D ratios available


Output depending on the power/torque of the driving solution and the material to be produced


Several options of base frames and adjustments to the extrusion centre axis to better suit customers’ needs.

Models

Screw OD(mm)
30
45
60
75
90
100
120
160
L/D(mm)
25D
25D
25D
25D
25D
25D
25D
25D
30D
30D
30D
30D
30D
30D
30D
30D
33D
33D
33D
33D
33D
33D
33D
33D
